Technical parameters

Value

Input

Connection

Single phase-2-wire, 3-phase-3-wire, 3-phase-4-wire

Frequency

45-65Hz

Voltage

Rating:

single-phase :AC 100V、400V

Three-phase: AC 3×57.7V/100V(100V)、

3×220V/380V(400V)、3×380V/660V(660V)(96 size only)

Note：72 profile not suitable for high voltage

applications

Overload:1.2 fold rating(continuous);2 fold rating for

1 second

Power consumption:< 0.5VA

Current

Rating: AC IA、5A

Overload:1.2 fold rating(continuous);10 fold rating

for 1 second

Power consumption:< 0.5VA

Output

Electric energy

Output mode:open-collector photo-coupler pulse

Pulse constant: 10000imp/kWh(settable)，see

wiring diagram for details；

Communication

RS485port, Modbus -RTU protocol

baud rate 1200 ~ 38400

Function

Switching input

Dry contact input, built-in power supply;

Switching output

Output mode: Relay normally open contact output

Contact capacity: AC 250V/3A、 DC 30V/3A

Analog output

1-5V,4 - 20mA

 Accuracy class

Frequency:0.05Hz,Current、Voltage:0.2 class,

Reactive power:l .0class, active power:0.5class,

active electric energy: 0.5class,2-31th harmonic

measurement:±1.0%

 Power supply

AC/DC 85-265V or DC24V（±20%）or DC48V(±20%)

power consumption≤10VA

Security

Power frequency withstand voltage

Between Power supply//Switching Output//

Current Input//voltage Input and Transmitting// Communication //

Pulse Output//switching input AC 2 kV 1min;

Between Power supply、switching output、

Current Input、voltage Input AC 2 kV 1min;

Between Transmitting、Communication、

Pulse Output、switching input AC 1kV 1 min;

Insulation resistance

Input、Output end to machine enclosure >100MΩ

Environment

Temperature

work: -10°C~+55°C  storage: -25°C ~+70°C

Humidity

≤95%RH Non-condensing

Altitude

≤2500m
